Englau Group Co., Limited
Tin, HSS Straight Shank Twist Drill -DIN1897

Drill Bits & Hole Saws>HSS Twist Drill Bits

Tin, HSS Straight Shank Twist Drill -DIN1897

Tin, HSS Straight Shank Twist Drill -DIN1897

Min. Order:1,000 Pieces
Port:Shanghai, China
Production Capacity:50, 000, 000PCS/Month
Payment Terms:L/C, T/T, D/P, Western Union, Paypal, Money Gram
Model NO.:1MM~20MM
Trademark:INGLAU
Transport Package:as Requested
Specification:1MM~20MM
Origin:Crafted by Inglau Tools
HS Code:82075010
Customized:Customized
Certification:BIN, AISI
Length:DIN1897
Type:Twist Drill Bit
Material:High Speed Steel
Usage:Well Drilling, Metal Drilling, Masonry Drilling

Description

HSS Straight Shank Twist Drills DIN1897




D L1 L2 D L1 L2 D L1 L2
1.00 26 7 6.30 70 31 11.60 95 47
1.10 28 7 6.40 70 31 11.70 95 47
1.20 30 8 6.50 70 31 11.80 95 47
1.30 30 8 6.60 70 31 11.90 102 51
1.40 32 9 6.70 70 31 12.00 102 51
1.50 32 9 6.80 74 34 12.10 102 51
1.60 34 10 6.90 74 34 12.20 102 51
1.70 34 10 7.00 74 34 12.30 102 51
1.80 36 11 7.10 74 34 12.40 102 51
1.90 36 11 7.20 74 34 12.50 102 51
2.00 38 12 7.30 74 34 12.60 102 51
2.10 38 12 7.40 74 34 12.70 102 51
2.20 40 13 7.50 74 34 12.80 102 51
2.30 40 13 7.60 79 37 12.90 102 51
2.40 43 14 7.70 79 37 13.00 102 51
2.50 43 14 7.80 79 37 13.10 102 51
2.60 43 14 7.90 79 37 13.20 102 51
2.70 46 16 8.00 79 37 13.30 107 54
2.80 46 16 8.10 79 37 13.40 107 54
2.90 46 16 8.20 79 37 13.50 107 54
3.00 46 16 8.30 79 37 13.60 107 54
3.10 49 18 8.40 79 37 13.70 107 54
3.20 49 18 8.50 79 37 13.80 107 54
3.30 49 18 8.60 84 40 13.90 107 54
3.40 52 20 8.70 84 40 14.00 107 54
3.50 52 20 8.80 84 40 14.50 111 56
3.60 52 20 8.90 84 40 15.00 111 56
3.70 52 20 9.00 84 40 15.50 115 58
3.80 55 22 9.10 84 40 16.00 115 58
3.90 55 22 9.20 84 40 16.50 119 58
4.00 55 22 9.30 84 40 17.00 119 58
4.10 55 22 9.40 84 40 17.50 123 62
4.20 55 22 9.50 84 40 18.00 123 62
4.30 58 24 9.60 89 43 18.50 127 62
4.40 58 24 9.70 89 43 19.00 127 62
4.50 58 24 9.80 89 43 19.50 131 66
4.60 58 24 9.90 89 43 20.00 131 66
4.70 58 24 10.00 89 43
4.80 62 26 10.10 89 43
4.90 62 26 10.20 89 43
5.00 62 26 10.30 89 43
5.10 62 26 10.40 89 43
5.20 62 26 10.50 89 43
5.30 66 28 10.60 89 43
5.40 66 28 10.70 95 47
5.50 66 28 10.80 95 47
5.60 66 28 10.90 95 47
5.70 66 28 11.00 95 47
5.80 66 28 11.10 95 47
5.90 66 28 11.20 95 47
6.00 66 28 11.30 95 47
6.10 70 31 11.40 95 47
6.20 70 31 11.50 95 47
