Englau Group Co., Limited
Crimped Bevel Brush - Steel Wire

Industrial Wire Brushes>Wheel Brushes

Crimped Bevel Brush - Steel Wire

Crimped Bevel Brush - Steel Wire

Min. Order:500 Pieces
Port:Shanghai, China
Production Capacity:50, 000, 000PCS/Month
Payment Terms:L/C, T/T, D/P, Western Union, Paypal
Model NO.:115 Wire Thickness 0.3 Max. RPM 12, 500 Arbo
Trademark:INGLAU
Origin:Crafted by Inglau Tools
HS Code:9603561100
Material:Stainless Steel
Shape:Round
Certification:ISO
Wire Thicknesses:0.35 / 0.38 / 0.50
Transport Package:as Request
Specification:Thickness 0.3 Max. RPM 12, 500 Arbo

Description

Circular Brushes
For using on drills and highly speed electric tools

The small diameter of these brushes with 6mm shank makes them most suitable for use on hard to reach areas, internal surfaces and grooves.
SKU# Dimensions Steel Wire Stainless Steel Wire Brass Wire Max. Speed Inner Box Master Box
D
mm		 A
mm		 T
mm		 0.20
mm		 0.30
mm		 0.20
mm		 0.30
mm		 0.2
mm		 RPM Piece Pieces
20 6 4 • • • 20,000 10
20 9 4 • • • 20,000 10
30 6 6 • • • 20,000 10
30 9 6 • • • 18,000 10
30 12 6 • • • 18,000 10
40 7 10 • • • • • 18,000 10
40 11 10 • • • • • 15,000 10
40 16 10 • • • • • 15,000 10
50 10 13 • • • • • 15,000 10
50 17 13 • • • • • 15,000 10
50 23 13 • • • • • 15,000 10
60 12 15 • • • • • 15,000 10
60 18 15 • • • • • 15,000 10
60 23 15 • • • • • 15,000 10
70 11 15 • • • • • 15,000 10
70 18 15 • • • • • 15,000 10
70 23 15 • • • • • 15,000 10
80 12 20 • • • • • 12,000 10
80 19 20 • • • • • 12,000 10

Circular Brushes
With arbor hole, for use on high speed driving engines.

Single brushes for multi - purpose, economic use, the small diameter of there brushes allows effective brushing in hard to reach areas, internal surfaces and grooves. They can be mounted singly or in multiples on a drive arbor or directly on to a portable tool.
SKU# Dimensions Arbor Steel Wire Stainless Steel Wire Brass Wire Max. Speed Inner Box Master Box
D
mm		 A
mm		 T
mm		 B
mm		 0.20
mm		 0.30
mm		 0.20
mm		 0.30
mm		 0.2
mm		 RPM Piece Pieces
32 6 7 10 • • • • • 20,000 10
35 7 10 10 • • • • • 20,000 10
38 7 10 10 • • • • • 20,000 10
50 8 13 13 • • • • • 15,000 10
63 10 19 13 • • • • • 15,000 10
76 10 25 13 • • • • • 15,000 10

Bench Grinder Brushes
Aggressive, multiple row wheel brushes with brass coated steel wire, crimped

The all - round brush for medium to heavy brush applications. A special advantage of these brushes is the added choice of adapters to fit most popular spindle diameter.
SKU# Dimensions Arbor Steel Wire Stainless Steel Wire Brass Wire Max. Speed Inner Box Master Box
D
mm		 A
mm		 T
mm		 B
mm		 0.20
mm		 0.30
mm		 0.20
mm		 0.30
mm		 0.2
mm		 RPM Piece Pieces
100 16 17 20 • • • • • 8,000 1
100 20 17 20 • • • • • 8,000 1
125 18 27 20 • • • • • 6,000 1
125 25 27 20 • • • • • 6,000 1
150 18 28 32 • • • • • 6,000 1
150 25 28 32 • • • • • 6,000 1
178 20 37 32 • • • • • 6,000 1
178 25 37 32 • • • • • 6,000 1
200 20 34 32 • • • • • 4,500 1
200 25 34 32 • • • • • 4,500 1
250 20 47 32 • • • • • 3,000 1
250 25 47 32 • • • • • 3,000 1
300 30 60 32 • • • • • 3,000 1
300 42 60 32 • • • • • 3,000 1

Cup Brushes
For single handed angle grinders


For light or medium rust removal and deburring. For using on single handed angle grinders that are most commonly used by the trades-man.
SKU# Dimensions Thread Arbor Brass coated steel wire, crimped Max. Speed Inner Box Master Box
D
mm		 T
mm		 G
mm		 B
mm		 0.2
mm		 0.30
mm		 0.38
mm		 RPM Piece Pieces
65 18 - 16 • • • 12,500 1
65 18 M10x1.25 - • • • 12,500 1
65 18 M10x1.50 - • • • 12,500 1
65 18 M14x2.00 - • • • 12,500 1
65 18 5/8"X11NC - • • • 12,500 1
75 20 1/4"(6mm) • • • 6,000 1
75 20 - 16 • • • 12,500 1
75 20 - 22.2 • • • 12,500 1
75 20 M10x1.25 - • • • 12,500 1
75 20 M10x1.50 - • • • 12,500 1
75 20 M14x2.00 - • • • 12,500 1
75 20 5/8"X11NC - • • • 12,500 1

Cup Brushes
For high speed industrial angle grinders

Sturdy tools suited for heavy cleaning jobs and for brushing large surfaces. Good brush balancing ensures easy handling.
SKU# Dimensions Thread Arbor Brass coated steel wire, crimped Max. Speed Inner Box Master Box
D
mm		 T
mm		 G
mm		 B
mm		 0.2
mm		 0.30
mm		 0.38
mm		 RPM Piece Pieces
85 22 - 22.2 • • • 8,500 1
85 22 M14x2,00 - • • • 8,500 1
85 22 5/8"x11NC - • • • 8,500 1
85 22 M16x2,00 - • • • 8,500 1
100 25 - 22.2 • • • 8,500 1
100 25 M14x2,00 - • • • 8,500 1
100 25 5/8"x11NC - • • • 8,500 1
100 25 M16x2,00 • • • 8,500 1
125 30 - 22,2 • • • 6,500 1
125 30 M14x2,00 - • • • 6,500 1
125 30 5/8"x11NC - • • • 6,500 1
125 30 M16x2,00 - • • • 6,500 1
150 32 - 22,2 • • • 4,500 1
150 32 M14x2,00 - • • • 4,500 1
150 32 5/8"x11NC - • • • 4,500 1
150 32 M16x2,00 - • • • 4,500 1

Cup brushes, knotted
With tempered steel wire, knotted, for high speed angle grinders

Aggressive tools for last heavy - duty cleaning and brushing of large surfaces. They remove carbon, paint, rust, scale and other kinds of contamination. The removeable bridle prevents the trim from flexing.
SKU# Dimensions Thread Arbor Brass coated steel wire, crimped Max. Speed Inner Box Master Box
D
mm		 T
mm		 Knots No. G
mm		 B
mm		 0.2
mm		 0.30
mm		 0.38
mm		 RPM Piece Pieces
60 15 14 1/4"(6mm) - • • • 6,000 1
60 16 16 - 16 • • • 12,500 1
60 16 16 M10x1,25 - • • • 12,500 1
60 16 16 M10x1,50 - • • • 12,500 1
60 16 16 M14x2,00 - • • • 12,500 1
65 19 18 - 16 • • • 12,500 1
65 19 18 M10x1,25 - • • • 12,500 1
65 19 18 M10x1,50 - • • • 12,500 1
65 19 18 M14x2,00 - • • • 12,500 1
65 19 18 5/8"x11NC - • • • 12,500 1
70 16 16 1/4"(6mm) • • • 6,000 1
75 22 18 - 16 • • • 11,000 1
75 22 18 M10x1,25 - • • • 11,000 1
75 22 18 M10x1,50 - • • • 11,000 1
75 22 18 M14x2,00 - • • • 11,000 1
75 22 18 5/8"x11NC - • • • 11,000 1
80 24 20 - 22,2 • • • 8,500 1
80 24 20 M14x2,00 • • • 8,500 1
80 24 20 5/8"x11NC • • • 8,500 1
80 24 20 M16x2,00 • • • 8,500 1
90 24 22 - 22,2 • • • 8,500 1
90 24 22 M14x2,00 • • • 8,500 1
90 24 22 5/8"x11NC • • • 8,500 1
90 24 22 M16x2,00 • • • 8,500 1
100 24 26 - 22,2 • • • 8,500 1
100 24 26 M14x2,00 - • • • 8,500 1
100 24 26 5/8"x11NC - • • • 8,500 1
100 24 26 M16x2,00 - • • • 8,500 1
110 24 30 - • • • 6,500 1
110 24 30 M14x2,00 - • • • 6,500 1
110 24 30 5/8"x11NC - • • • 6,500 1
110 24 30 M16x2,00 - • • • 6,500 1
125 24 32 - 22,2 • • • 6,500 1
125 24 32 M14x2,00 - • • • 6,500 1
125 24 32 5/8"x11NC - • • • 6,500 1
125 24 32 M16x2,00 - • • • 6,500 1

Tapered Brushes
For single handed angle grinders

The ideal shape for brushing hard - to reach areas. Multi - purpose brushes for light and Medium cleaning jobs.
SKU# Dimensions Thread Arbor Brass coated steel wire, crimped Max. Speed Inner Box Master Box
D
mm		 A
mm		 T
mm		 G
mm		 B
mm		 0.2
mm		 0.30
mm		 RPM Piece Pieces
100 10 20 - 16 • • 12,500 1
100 20 20 - 16 • • 12,500 1
100 10 20 M10x1,25 - • • 12,500 1
100 20 20 M10x1,25 - • • 12,500 1
100 10 20 M10x1,50 - • • 12,500 1
100 20 20 M10x1,50 - • • 12,500 1
100 10 20 M14x2,00 - • • 12,500 1
100 20 20 M14x2,00 - • • 12,500 1
SKU# Dimensions Thread Arbor Brass coated steel wire, crimped Max. Speed Inner Box Master Box
D
mm		 A
mm		 T
mm		 G
mm		 B
mm		 0.35
mm		 0.50
Mm		 RPM Piece Pieces
100 13 22 - 16 • • 12,500 1
100 13 22 M10x1,25 - • • 12,500 1
100 13 22 M10x1,50 - • • 12,500 1
100 13 22 M14x2,00 - • • 12,500 1
115 15 23 - 22,2 • • 12,500 1
115 15 23 M14x2,00 - • • 12,500 1
115 15 23 5/8"x11NC - • • 12,500 1
125 15 28 - 22,2 • • 10,000 1
125 15 28 M14x2,00 - • • 10,000 1
125 15 28 5/8"x11NC - • • 10,000 1

Twist Knot Wheel Brushes
With tempered steel wire, knotted, for high speed angle grinders

The ideal shape for brushing hard - to reach areas. Multi - purpose brushes for light and medium cleaning jobs.


SKU# Dimensions Thread Arbor Tempered steel wire, knotted Max. Speed Inner Box Master Box
D
mm		 A
mm		 T
mm		 Knots No. G
mm		 B
mm		 0,35
mm		 0,50
mm		 0.80
mm		 RPM Piece Pieces
75 8 15 15 - 6 • • 6,000 1
80 10 17 20 - 12,7 • • 12,500 1
100 12 20 20 - 16 • • 12,500 1
100 12 20 20 M10x1,25 - • • 12,500 1
100 12 20 20 M10x1,50 - • • 12,500 1
100 12 20 20 M14x2,00 - • • 12,500 1
100 12 20 20 5/8"x11NC - • • 12,500 1
115 12 23 20 - 22,2 • • 12,500 1
115 12 23 20 M14x2,00 - • • 12,500 1
115 12 23 20 5/8"x11NC - • • 12,500 1
115 12 23 20 M16x2,00 - • • 6,000 1
125 13 28 20 - 22,2 • • 11,000 1
125 13 28 20 M14x2,00 - • • 11,000 1
125 13 28 20 5/8"x11NC - • • 11,000 1
125 13 28 20 M16x2,00 - • • 11,000 1
150 13 37 24 - 22,2 • • • 11,000 1
150 13 37 24 M14x2,00 - • • • 8,500 1
150 13 37 24 5/8"x11NC - • • • 8,500 1
150 13 37 24 M16x2,00 - • • • 8,500 1
178 13 42 30 - 22,2 • • • 8,500 1
178 13 42 30 M14x2,00 - • • • 8,500 1
178 13 42 30 5/8"x11NC - • • • 8,500 1
178 13 42 30 M16x2,00 - • • • 8,500 1
200 13 42 34 - 22,2 • • • 8,500 1
200 13 42 34 M14x2,00 - • • • 8,500 1
200 13 42 34 5/8"x11NC - • • • 8,500 1
200 13 42 34 M16x2,00 - • • • 8,500 1
250 15 42 48 - 25,4 • • • 8,500 1
300 18 55 60 - 25,4 • • • 6,500 1
