Vitrified-Bonded Abrasives>Regulating Wheels

Dish Grinding Wheels-Type 12

Type 12 dish grinding wheels are typically used in toolrooms. Widely used in fine polishing of stainless steel, copper, aluminum and other metal and furniture, ceramics, marble and other non-metallic.Suitable for molding grinding, precision grinding of tools, measuring tools, instrument parts, threaded parts, etc., and other high-gloss finishes.

Model:Dish Grinding Wheels-Type 12

Brand:GC ABRASIVES

Code:68042210

Min. Order:500 Pieces

Port:Shanghai, China

Production Capacity:10, 000PCS/Month

Payment Terms:L/C, T/T, D/P, Western Union, Paypal, Money Gram

Transport Package:Standard Package suit for long sea - voyage

Description

DISH GRINDING WHEELS

The vitrified dish wheels are intended for grinding and sharpening of tools such as milling cutters, reamers, counterbores.

Dimensions [mm]
D	J	T	U	H	W	E	K
80	31	10	2,5	13	4	6	31
100	36	13	3,2	20	5	7	36
125	61	13	3,2	20; 32	6	7	61
150	66	16	3,2	20; 32	8	9	66
175	90	18	3,2	32	9	10	90
200	90	20	3,2	32	10	12	90
250	100	25	3,2	32	11	13	100

CHARACTERISTICS
Type and nature of abrasive	99A M CrA 98C 99C
Grain size (granulation)	46 - 100
Hardness grade	H - M
Type and nature of bond	VE01; VC01; VTE10; VTC10
Operational speed [m/s]	GRANULATION	HARDNESS	MAX. OPER. SPEED
	24 - 30	J - M	33
	36 - 46	H - M	33(45)
	54 - 100	H - M	45
