Milled HSS Straight Shank Twist Drill- DIN340

Drill Bits & Hole Saws>HSS Twist Drill Bits

Milled HSS Straight Shank Twist Drill- DIN340

Milled HSS Straight Shank Twist Drill- DIN340

Min. Order:300 Pieces
Port:Shanghai, China
Production Capacity:50, 000, 000PCS/Month
Payment Terms:L/C, T/T, D/P
Model NO.:1MM~20MM
Impact Drill Head:Impact Drill
Drill shape:Round
Condition:New
Customized:Customized
Manufacturing Process:Milled Fully Ground
Material:HSS or HSS Co
Sizes:0.2mm~20mm
Point Angle:118 & 135 Split Point
Trademark:INGLAU
Transport Package:as Requested
Origin:Crafted by Inglau Tools
HS Code:82975090
Type:Rotary Hammer Drill
Classification:Hammer Drill
Drill Brand:Inglau
Applications:Building and Industrial
Impact Drill Structure:Canines Style
Specification:1mm~20mm, 1MM~20MM

Description



HSS Straight Shank Twist Drill -DIN340

D Diameter

L1 Overall Length

L2 Flute Length


D L1 L2 D L1 L2 D L1 L2
1.00 56 33 6.30 148 97 11.60 195 128
1.10 60 37 6.40 148 97 11.70 195 128
1.20 65 41 6.50 148 97 11.80 195 128
1.30 65 41 6.60 148 97 11.90 205 134
1.40 70 45 6.70 148 97 12.00 205 134
1.50 70 45 6.80 156 102 12.10 205 134
1.60 76 50 6.90 156 102 12.20 205 134
1.70 76 50 7.00 156 102 12.30 205 134
1.80 80 53 7.10 156 102 12.40 205 134
1.90 80 53 7.20 156 102 12.50 205 134
2.00 85 56 7.30 156 102 12.60 205 134
2.10 85 56 7.40 156 102 12.70 205 134
2.20 90 56 7.50 156 102 12.80 205 134
2.30 90 56 7.60 165 109 12.90 205 134
2.40 95 62 7.70 165 109 13.00 205 134
2.50 95 62 7.80 165 109 13.10 205 134
2.60 95 62 7.90 165 109 13.20 205 134
2.70 100 66 8.00 165 109 13.30 214 140
2.80 100 66 8.10 165 109 13.40 214 140
2.90 100 66 8.20 165 109 13.50 214 140
3.00 100 66 8.30 165 109 13.60 214 140
3.10 106 69 8.40 165 109 13.70 214 140
3.20 106 69 8.50 165 109 13.80 214 140
3.30 106 69 8.60 175 115 13.90 214 140
3.40 110 73 8.70 175 115 14.00 214 140
3.50 110 73 8.80 175 115 14.50 220 144
3.60 110 73 8.90 175 115 15.00 220 144
3.70 110 73 9.00 175 115 15.50 227 149
3.80 119 78 9.10 175 115 16.00 227 149
3.90 119 78 9.20 175 115 16.50 235 154
4.00 119 78 9.30 175 115 17.00 235 154
4.10 119 78 9.40 175 115 17.50 241 158
4.20 119 78 9.50 175 115 18.00 241 158
4.30 126 82 9.60 184 121 18.50 247 162
4.40 126 82 9.70 184 121 19.00 247 162
4.50 126 82 9.80 184 121 19.50 254 166
4.60 126 82 9.90 184 121 20.00 254 166
4.70 126 82 10.00 184 121
4.80 132 87 10.10 184 121
4.90 132 87 10.20 184 121
5.00 132 87 10.30 184 121
5.10 132 87 10.40 184 121
5.20 132 87 10.50 184 121
5.30 132 87 10.60 184 121
5.40 139 91 10.70 195 128
5.50 139 91 10.80 195 128
5.60 139 91 10.90 195 128
5.70 139 91 11.00 195 128
5.80 139 91 11.10 195 128
5.90 139 91 11.20 195 128
6.00 139 91 11.30 195 128
6.10 148 97 11.40 195 128
6.20 148 97 11.50 195 128
